Bulk import 60GHz cnWave Devices

This article explains how to add 60GHz cnWave devices in bulk using csv file in cnMaestro

Make sure the External or Onboard E2E controller is managed in cnMaestro

Download Sample Template

  1. Navigate to Inventory > E2E Network and click on Import button

  2. Import Device(s) Configuration window pops up. Click on Download Template
    to download sample template (csv format)

    Below is sample csv template looks like

Entering data and importing csv file

  1. Enter all the fields with appropriate data and save it
  2. Again navigate to Inventory > E2E Network and click on Import button
  3. Click on Select File and select the csv file saved in step1

  1. If entered data is correct, Data validated Successfully message displays and click on Import button to add all 60GHz cnWave devices in bulk

  1. If entered data is incorrect in csv file, appropriate errors will displays. Below is the sample error

  2. Once data is corrected, click on Validate button. Data Validated Successfully message displays if correct data is entered. Optional Download Modified Data if required

  3. Now click on Import button to add the 60GHz cnWave devices in bulk in cnMaestro

How to export multiple 60GHz cnWave Devices in cnMaestro

Navigate to Inventory > E2E Network and select 60GHz cnWave devices which
you want to export. Now click on Export button, csv file will be downloaded.

How to delete multiple 60GHz cnWave devices

Navigate to Inventory > E2E Network and select 60GHz cnWave devices which you
want to delete. Now click on Delete button to delete from cnMaestro inventory
